Rated capacity: AC-15 220V/4.5A 380V/2.5A 660V/1A
DC-13 24V/6A 48V/3A 110V/0.6A 220V/0.3A
Contact resistance:Silver alloy contact ≤50mΩ
Max .Isolation voltage:AC 2500V 50Hz 1min
Mechanical life:Flat type ≥3×106
Knob type ≥3×105
Key type≥5×104
Emergency stop button ≥5×104
Electrical life:≥60×104
Conventional thermal current:Ith 10A
Rated Isolation voltage:Ui AC660V
Ambient temperature:-25℃~+55℃
Degree of protection:IP65
